Aperçu technique
Kit cadre
Cadre:
Crossmachine CXA01 | Al-13 Premium Triple-butted - Hydroformed Aluminum
Cockpit
Cintre:
BMC RDB 03
Potence:
BMC RSM 03
Tige de Selle:
TCC 01 Premium Carbon Compliance-Post | 18mm o
Selle:
Selle Royal Saba
Seat
Seatpost:
TCC 01 Premium Carbon Compliance-Post | 18mm o
Saddle:
Selle Royal Saba
Transmission
Vitesses:
1 x 11
Pédalier:
Sram Rival 1 | 40T
Cassette:
SRAM APEX | 11-42T
Chaîne:
KMC X11-1
Dérailleur Arrière:
Sram Rival
Leviers de Vitesses:
Sram Rival HRD
Freins
Leviers de Frein / Étriers:
Sram Rival HRD-A1 | Hydraulic
Roues
Jantes:
DT Swiss X-1900 Spline
Moyeux:
DT Swiss X-1900 Spline | Centerlock
Pneus:
Continental Cyclocross Race | 35mm
| Size | 48 | 51 | 54 | 56 | 58 | 61 |
|---|---|---|---|---|---|---|
| Rider Height | ||||||
| Reach | 354 | 359 | 369 | 378 | 388 | 398 |
| Stack | 527 | 542 | 559 | 578 | 595 | 613 |
| Bar Drop | 125 | 125 | 125 | 125 | 125 | 125 |
| Bar Reach | 70 | 70 | 70 | 70 | 70 | 70 |
| Bar Rise | ||||||
| Bar Sweep | ||||||
| Bar Width | 420 | 420 | 420 | 440 | 440 | 440 |
| Base Bar Drop Flat Cockpit | ||||||
| Base Bar Drop V-Cockpit | ||||||
| Base Bar Reach Flat Cockpit | ||||||
| Base Bar Reach V-Cockpit | ||||||
| BB Drop | 68 | 68 | 68 | 68 | 68 | 68 |
| BB Drop (SLACK) | ||||||
| BB Drop (STEEP) | ||||||
| BB Height (SLACK) | ||||||
| BB Height (STEEP) | ||||||
| Chainstay | ||||||
| Crank Length | 170 | 170 | 172.5 | 172.5 | 172.5 | 175 |
| LT | BB Drop (SLACK) | ||||||
| LT | BB Drop (STEEP) | ||||||
| LT | BB Height (SLACK) | ||||||
| LT | BB Height (STEEP) | ||||||
| LT | Chainstay | ||||||
| LT | Fork Length | ||||||
| LT | Fork Rake | ||||||
| LT | Frame Size | ||||||
| LT | Front Center (SLACK) | ||||||
| LT | Front Center (STEEP) | ||||||
| LT | Head Tube | ||||||
| LT | HT Angle (SLACK) | ||||||
| LT | HT Angle (STEEP) | ||||||
| LT | Reach (SLACK) | ||||||
| LT | Reach (STEEP) | ||||||
| LT | Rider Height | ||||||
| LT | Seat Tube | ||||||
| LT | ST Angle @750mm Saddle Height (SLACK) | ||||||
| LT | ST Angle @750mm Saddle Height (STEEP) | ||||||
| LT | ST Angle Actual (SLACK) | ||||||
| LT | ST Angle Actual (STEEP) | ||||||
| LT | ST Angle Effective (SLACK) | ||||||
| LT | ST Angle Effective (STEEP) | ||||||
| LT | Stack (SLACK) | ||||||
| LT | Stack (STEEP) | ||||||
| LT | Stand Over Height (80 in Front of BB) | ||||||
| LT | Stand Over Height (Lowest Point) | ||||||
| LT | Top Tube (SLACK) | ||||||
| LT | Top Tube (STEEP) | ||||||
| LT | Wheelbase (SLACK) | ||||||
| LT | Wheelbase (STEEP) | ||||||
| ST | BB Drop (SLACK) | ||||||
| ST | BB Drop (STEEP) | ||||||
| ST | BB Height (STACK) | ||||||
| ST | BB Height (STEEP) | ||||||
| ST | Chainstay | ||||||
| ST | Fork Length | ||||||
| ST | Fork Rake | ||||||
| ST | Frame Size | ||||||
| ST | Front Center (SLACK) | ||||||
| ST | Front Center (STEEP) | ||||||
| ST | Head Tube | ||||||
| ST | HT Angle (SLACK) | ||||||
| ST | HT Angle (STEEP) | ||||||
| ST | Reach (SLACK) | ||||||
| ST | Reach (STEEP) | ||||||
| ST | Rider Height | ||||||
| ST | Seat Tube | ||||||
| ST | ST Angle @750mm Saddle Height (SLACK) | ||||||
| ST | ST Angle @750mm Saddle Height (STEEP) | ||||||
| ST | ST Angle Actual (SLACK) | ||||||
| ST | ST Angle Actual (STEEP) | ||||||
| ST | ST Angle Effective (SLACK) | ||||||
| ST | ST Angle Effective (STEEP) | ||||||
| ST | Stack (SLACK) | ||||||
| ST | Stack (STEEP) | ||||||
| ST | Stand Over Height (80 in Front of BB) | ||||||
| ST | Stand Over Height (Lowest Point) | ||||||
| ST | Top Tube (SLACK) | ||||||
| ST | Top Tube (STEEP) | ||||||
| ST | Wheelbase (SLACK) | ||||||
| ST | Wheelbase (STEEP) | ||||||
| Fork Length | 395 | 395 | 395 | 395 | 395 | 395 |
| Fork Rake | 45 | 45 | 45 | 45 | 45 | 45 |
| Frame Size | ||||||
| Front Center | 568 | 574 | 585 | 600 | 610 | 626 |
| Front Center (SLACK) | ||||||
| Front Center (STEEP) | ||||||
| Head Tube | 110 | 125 | 140 | 160 | 176 | 195 |
| Head Tube Angle | 70.5 | 71 | 71.5 | 71.5 | 72 | 72 |
| HT Angle (SLACK) | ||||||
| HT Angle (STEEP) | ||||||
| Pad Reach Flat Cockpit | ||||||
| Pad Reach V-Cockpit | ||||||
| Pad Stack Flat Cockpit | ||||||
| Pad Stack V-Cockpit | ||||||
| Reach (SLACK) | ||||||
| Reach (STEEP) | ||||||
| Rear Center | 425 | 425 | 425 | 425 | 425 | 425 |
| Saddle Height Range | ||||||
| Seat Angle | 73 | 73 | 73 | 73 | 73 | 73 |
| Seat Tube | 480 | 510 | 540 | 560 | 580 | 610 |
| Seatpost Drop | ||||||
| Seatpost Length | 350 | 350 | 350 | 350 | 350 | 350 |
| Seatpost Offset | 18 | 18 | 18 | 18 | 18 | 18 |
| ST Angle @750mm Saddle Height (SLACK) | ||||||
| ST Angle @750mm Saddle Height (STEEP) | ||||||
| ST Angle Actual (SLACK) | ||||||
| ST Angle Actual (STEEP) | ||||||
| ST Angle Effective (SLACK) | ||||||
| ST Angle Effective (STEEP) | ||||||
| Stack (SLACK) | ||||||
| Stack (STEEP) | ||||||
| Stand Over Height (80 in Front of BB) | ||||||
| Stand Over Height (Lowest Point) | ||||||
| Standover Height | ||||||
| Stem Angle | 6 | 6 | 6 | 6 | 6 | 6 |
| Stem Length | 90 | 100 | 110 | 110 | 130 | 130 |
| Top Tube | 515 | 525 | 540 | 556 | 570 | 595 |
| Top Tube (SLACK) | ||||||
| Top Tube (STEEP) | ||||||
| Trail | 72 | 69 | 66 | 66 | 63 | 63 |
| Wheelbase | 984 | 990 | 1000 | 1016 | 1026 | 1041 |
| Wheelbase (SLACK) | ||||||
| Wheelbase (STEEP) |
